△ Android 7.1.2
△ HDMI 2.0
△ Low Cost
△ Personalized User Interface (Hotel/Hospital/Community…)
△ Advertisement System (ADS) Imbedded
Specifications
|
Hardware
|
CPU |
RK3229, 28nm Quad core Cortex A7, High cost performance 4K OTT Box solution |
|
GPU |
ARM Mali-400 GPU |
|
|
HDMI |
Including an HDMI 2.0 for HDMI 2.0 for 4K YUV420@60Hz with HDCP 1.4/2.2 |
|
|
Support 4K 10-bit H.265/H.264/VP9 video playback and display |
||
|
Memory |
1GB DDRIII |
|
|
Flash |
8GB Nand Flash |
|
|
WiFi |
2.4G，802.11 b/g/n, |
|
|
Wired network |
Ethernet GMAC 10/100/100M Ethernet controller |
|
|
Support 10/100/1000 data transfer rate and RGMII interface |
||
|
Support 10/100Mbps data transfer rate and RGMII interface |
||
|
IR |
Infra Remote control |
|
|
Power Supply |
DC input 5V/2A |
|
|
Software
|
OS |
Android 7.1 |
|
3D |
Hardward 3D graphics acceleration |
|
|
Video decoding |
4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder |
|
|
1080P other video decoders (VC-1, MPEG-1/2/4, VP6/8) |
||
|
Support conversion from BT.2020 to Rec.709/Rec.601 |
||
|
Video post processor: de-interlace |
||
|
H.263/H.264 2160P@ 24fps VC-1 ,MPEG - 1 1080p @ 60fps MPEG- 2 2160P @ 24fps MPEG-4 1080P @ 60fps AVS 1080p @ 60fps MVC 2160P @ 24fps WMV,3GP,MKV,ASF,3G2M4V,MJPEG,RV8,RV9,RV10 1080P@60fps |
||
|
Support HEVC decoder |
||
|
Support Main/Main10 HEVC/H.265 decoder, 4K @ 60FPS |
||
|
Support 4096x2304 resolution |
||
|
Support HDMI 720P-2160P FUII 3D HD( 2160P, 3840 * 2160 ), 4K+2 K |
||
|
Support flash11.1 |
||
|
Video Decoder format |
H.264,H.265,VP8,MVC(1080P) |
|
|
Video format |
Supports DIVD/DIVX/REAL8 / 9 / 10, RV, RM, RMVB, PMP, FLV, MP4, M4V, VOB, VP6, VP8 2160P @ 24fps |
|
|
Audio format |
Supports MP1, MP2, MP3, WMA, OGG, AAC, M4A , FLAC, APE, AMR, RA, WAV, etc |
|
|
Picture format |
Supports JPG, JPEG, BMP, GIF, PNG, JFIF etc Resolution 8192x8192 |
|
|
HDD file system |
FAT16 / FAT32 / NTFS |
|
|
Support Subtitle |
SRT, SMI, SUB, SSA, IDX+USB |
|
|
XBMC/KODI |
Support |
|
|
DRM |
Widewine Level1, DRM PlayReady ,Verimatrix, built in Trustzone, HDCP 2.2/1.4 |
|
|
Support language |
Chinese, English, Germany, Japanese, Korea etc. multilateral languages |
|
|
Stream In/Out |
1*HDMI 2.0 |
Built-in HDMI 2.0 transmitter including both controller and PHY with CEC and HDCP, 4K @ 60FPS max resolution output |
|
1* SD Card |
to 64GB |
|
|
4*USB HOST |
2High speed USB 2.0,support USB DISK and USB HDD |
|
|
1*SPDIF |
SPDIF output |
|
|
1*RJ45 |
Ethernet:10/100M, standard RJ-45 |
|
|
1*Power input |
5V/2A |
|
|
Accessories |
Gift box Power charger adapter HDMI cable (optional) IR remote control (optional) User's Manual |
|
|
Applications |
Online |
Browse all video websites, support Netflix, Hulu, Flixster, youtube etc |
|
Apps |
Apps download freely form android market, amazon appstore etc |
|
|
Medium |
Local Media playback, support HDD, U disck ,SD card |
|
|
Talk online |
Support SKYPE video call, MSN, facebook, twitter, QQ etc |
|
|
Others |
Support WiFi hotpiont, could be as a wireless router Support DLNA, Google TV Remote, LAN, 3D Moive, Email, office suit etc |
|
|
Packing |
Dimension |
118*118*25 mm |
|
Approx weight |
400g |
System Construction
Advantages
Personalized EPG Interface
* Personalized EPG interface for hotel, hospital, Community and other industries.
* System wallpaper is changeable and EPG content is editable.
* Various business modes blend in IPTV system
* Support modular interface and convenient to docking with third part manage software
Advertisement System—Value added Services
* Hotel, hospital and community version can support set up advertisement business to increase revenues.
* Ad modes include booting ad, Menu ad (only for hospital and community version), VOD ad, pictures and text ad etc.
Mass HD Programs
* 1080P/60Hz full HD video
* Mass resource of Video on Demand including movies, entertainments, factual shows and etc
* Live programs synchronized broadcast
Strength and After-sale Services
* Dexin IPTV system is with solid quality based on Dexin’s own DTV head-end equipment
* The whole system is self research and developed, which makes it easy for the after-sale maintenances
* Skilled after-sale supporting team
