DVB-T2+S2 HD Combo SET TOP BOX
Specification
1. DVB-T2 AND DVB-S2 Combo Receiver, support DVB-T/T2、DVB-C、DVB-S/S2
2. Fully SD/HD DVB-T/T2、DVB-C、DVB-S/S2 compliant, support full HD 1080p
3. Native 18V feed for DVB-S2 tuner
4. Support SD/HD MPEG2 and MPEG4 AVC H.264
5. SCPC & MCPC receivable from C/Ku band satellites
6. DiSEqC 1.0/1.1/1.2/1.3(USALS) supported
7. Universal LNB, NIT search supported
8. Auto and manually scan all available TV and radio channels
9. Powerful and highly effective 7-day EPG function
10. Multi-language menu, subtitle and audio output supported
11. USB 2.0 for PVR, TIMESHIFT ,DVR , software upgrade and media files playback
12. Support aspect ratio 16:9, 4:3,Pan&Scan,letter box.
13. Support parental local
14. Easy to use and attractive menu
15. Support OTA
16. Support various media files, including music, photo and movie files
Specification
|
Tuner and Demodulation parameter [ S2 ]: |
|
Input frequency: 950 to 2,150MHz |
|
Symbol rate: 1 to 45M |
|
Input impedance: 75 Ω |
|
Rate: 1/2, 2/3, 3/5, 3/4, 4/5, 5/6, 8/9, and 9/10 |
|
Tuner and Demodulation parameter[ T2/DVB-C ]: |
|
RF input frequency: 110-862Mhz , |
|
Bandwith: 1.7/5/6/7/8/10 MHz |
|
Demodulation: QPSK, 16QAM, 64QAM, 256QAM |
|
Scattered Pillots:1%/2%/4%/8% of total |
|
Code Rate: 1/2, 3/5,2/3, 3/4, 4/5, 5/6 |
|
Continual Pillots:0.35% of total |
|
Guard Interval: 1/4, 19/128, 1/8, 19/256 , 1/16 ,1/32, 1/128 |
|
Typical date rate(UK) 40 Mbit/s |
|
FFT Mode: from 1K ,2k,4k,8k,16k,32k |
|
Max.data rate(@20 db C/N):47.8Mbit/s |
|
Easy to use and attractive menu |
|
Common Interface for various CAS modules[ CA option ] |
|
RF input: 2 -F interface, one for T2(DVB-C), one for S2 |
|
Video output: 1- CVBS |
|
Audio output:1-RCA |
|
USB interface : 1 |
|
HDMI interface:1 |
|
Card slot: 1 |
|
DC input: 12V 1A |
|
|
